Removable Bundle and Externally Sealed Floating Tube sheet: Type AEW, BEW

No ability to absorb thermal expansion between the outer shell and tube bundle.

Shell side can only be cleaned by a chemical solution.

Less costly than removable bundle designs.

The tube sheet is welded to the shell and heads are bolts to the tube sheet. This design is the simplest design and most economical in most cases. Straight Tube and Fixed Tube Sheet: Types BEM, AEM, NEN, etc The figure below is helpful in visualizing each segment. IE: TEMA Type BEM would have the “B” representing the front head, the “E” the core or middle section and M representing the rear head designs. TEMA designations refer to portions of the unit that make up the complete heat exchanger. TEMA B and TEMA R are similar in requirements and typically require features like, confined gaskets joints, spiral wound gaskets along with some greater minimum thicknesses on some parts. TEMA C is the least restrictive and most widely used. There are 3 major TEMA classifications, which are as follows

Heat exchanger gasket chart install#

One of the advantages of selecting a shell & tube manufacturer that builds to TEMA specifications is that the end-user is assured that they will receive and install a piece of equipment that is built to certain specification’s and criteria. These standards define the style of heat exchanger and the machining and assembly tolerances. Reach us at 71.TEMA stands for “Tubular Exchangers Manufacturers Association” and is a set of standards that were developed by leading shell and tube manufacturers. Sealing Devices is an authorized Flexitallic spiral wound gasket and metal gasket supplier in addition to being a Flexitallic Allied Distributor. Whether you are looking for Thermiculite, Sigma, Flexpro ,Ring Type Joints (RTJ), Static Seals, Metal Jacketed Gaskets or the Flange Rescue Gasket, rely on our Inside Sales Team to meet your delivery needs. The Change Gasket is easy to handle and install as a double-jacketed gasket. The Flexitallic Change Gasket performs without fail 60% longer than any other heat exchanger gasket, spiral wound, double jacketed, CMG or Kammprofile gasket. This is manufactured using a 5-times thicker metal spiral and a unique laser welding process that penetrates completely through so it does not require an inner or outer ring. The metal-wound Change Heat Exchanger Gasket from Flexitallic is designed to deliver a most dynamic and resilient seal.

Heat exchanger gasket chart download#

The inner rings of style CGI spiral wound gaskets add strength against blowout and act as a compression stop.įor more information, download Spiral Wound / Metal Gasket Catalog as well as Corriculite CR235 corrosive filler datasheet for a look at extremely corrosive environments. Style CGI spiral wound gaskets are suitable for use on flat-face and raised-face flanges, and can be specified for high-pressure/temperature service or where corrosive or toxic media are present. Flexitallic Style CGI Spiral Wound Gaskets The CG spiral wound gasket is a good general purpose gasket and is suitable for use with flat-face and raised-face flanges.
